The Namkoo 50W slim LED floodlight combines SMD LEDs with an aluminium heat sink and a listed 100–240V input range. Consider the beam coverage and adjustable mounting position for your indoor or outdoor area-lighting layout. Confirm the selected configuration before installation.
1- Compact slim housing for outdoor accent lighting.
2- The die-cast aluminium body transfers heat from the LED assembly. Confirm the enclosure rating and installation conditions for the model.
3- The listed SMD2835 RGB option supports colour-changing programmes and 2.4G control. Confirm controller compatibility and available modes before ordering.
4- Confirm driver input, output and operating limits for the selected lamp.
Namkoo slim floodlight: confirm RGB/RGBW and enclosure rating for the selected model
| Model Reference | FL33 | ||||
| Power Options | 10W 20W 30W 50W 100W | ||||
| LED Package | SMD2835 | ||||
| Colour Mode | RGB | ||||
| White CRI: Verify | >70: confirm variant | ||||
| Input Voltage | 100-240V | ||||
| Control Options | Colour-changing programmes with 2.4G RF remote control; confirm receiver, remote and available modes | ||||
| Power Factor | >0.55 | ||||
| Listed Ratings | IP66 / IK08 | ||||
| Listed Size (mm) | 150x107x44 | ||||
| Beam Reference | 120° | ||||
| Housing Assembly | Aluminium housing, steel bracket and tempered glass | ||||
| Ambient Range | -35℃~+50℃ | ||||
| Humidity Range | 0%~90% | ||||
| Life / Warranty Reference | 30,000 h; confirm warranty | ||||
Model Selection
The slim floodlight range includes a 50 W reference alongside other listed power options. Confirm whether your application requires white light, RGB or RGBW. Select the actual model, control method and enclosure rating before comparing output or installation dimensions.
1. Input Supply: The reference lists 100–240 V input. Confirm the driver label, frequency and electrical installation requirements for the destination.
2. Power Selection: Match input wattage and measured light output to the application. Energy savings depend on operating hours, controls and the previous lighting arrangement.
3. Heat Dissipation: The aluminium housing carries heat away from the LED assembly. Keep the required clearance and follow the specified ambient limits.
4. Compact Housing: Verify the dimensions and bracket spacing for the selected wattage. One listed housing size may not apply to every power option.
5. Outdoor Assembly: Confirm housing seals, cable entry and mounting hardware for the exposure conditions. Follow the model installation instructions.
1. LED Colour Mode: The table lists SMD2835 RGB LEDs. Confirm any white-light or RGBW variant and its colour-rendering data separately.
2. Beam Coverage: A 120° beam is listed for broad coverage. Assess mounting distance and spill light rather than assuming a small floodlight suits a sports field.
3. Adjustable Mount: Set the bracket angle for the required target area and secure it according to the installation instructions. Confirm supporting-surface strength.
4. Enclosure Rating: The table lists IP66/IK08 while other text refers to IP65/IK09. Request the exact model datasheet and rating documentation before selection.
5. Service Planning: Confirm the 30,000-hour life reference, driver conditions and written warranty. Plan cleaning and periodic inspection for outdoor operation.
Namkoo Slim Floodlight: The listed RGB variant uses SMD2835 LEDs and a 2.4G control reference for colour-changing effects. Confirm remote compatibility, colour modes and the exact enclosure rating in the model datasheet. For general white illumination, request the corresponding white-light specification rather than using RGB colour-mode data.
Application Planning:
Installation Notes:
Operating Costs: Compare actual power, operating hours and control settings for the chosen variant. Ask Namkoo for the model datasheet and supply terms before ordering.
For a 50W slim floodlight enquiry, provide the area dimensions, mounting height and supply voltage. Include the preferred colour temperature and required fixture quantity. Namkoo can discuss the selected model and installation accessories. Confirm the beam spread, bracket dimensions and electrical connection before ordering.
